    Home / Produkty / Pumps 12 a 24 V / Membránové čerpadlo Create Flow CF51, max.výkon 18,9 l/min, max. 4,2 bar, samonasávací -1.8 m. Napájení 230 V AC Nejprodávanější čerpadlo

    Membránové čerpadlo Create Flow CF51, max.výkon 18,9 l/min, max. 4,2 bar, samonasávací -1.8 m. Napájení 230 V AC Nejprodávanější čerpadlo

    Code: CFFL557001T230V
    čerpadlo na 23V Create Flow
    157 € / pcs 190 € incl. VAT 157 € / 1 pcs
    Skladem (5 pcs)
    Delivery to:
    08/01/2025
    You will get for free
    Hose mandrel for the pump SEAFLO/Shurflo
    + Hose mandrel for the pump SEAFLO/Shurflo worth 2 €
    Filter for suction for pumps SEAFLO, SHURflo, Lilie
    + Filter for suction for pumps SEAFLO, SHURflo, Lilie worth 9 €

    Powerful 12 V pump for pumping water, aqueous solutions. Max. output 18.9 l/min, max. 4.2 bar, self-priming capacity -1.8 m. The pump is suitable for waterworks, water distribution in the house, cottage, boat. The pump is suitable for irrigation of flower beds, greenhouses. The pump is not designed for continuous operation. Ideal operating time approx. 20 - 30 min. The pump cannot pump petroleum products, diesel, oils and flammable liquids.

    For the pump we recommend ordering 50 µm suction filter a 2 x hose barbs.

    For an idea of the flow rate, we recommend watching the video here

    For an idea of the flow rate, we recommend watching the video here

    The pump is very often used for watering and fertilizing municipal greenery. The easy connection to the car battery and the storage of the pump on an IBC container guarantee a mobile spraying and watering system.

    The material combination of the pump is suitable for pumping urea, alkaline liquids, fertilizers, seawater... etc.

    Detailed information

    Related products

    Filtr 51S01
    Filter for suction for pumps SEAFLO, SHURflo, Lilie
    Skladem (15 pcs)
    11 € incl. VAT
    9 €

    Pump suction filter SEAFLO, SHURflo, Lilie, connection internal thread 1/2" MNPT, connection external thread 1/2" FNPT, easy to clean, material polypropylene, transparent...

    Code: 51S01
    Nástavec 51F01
    Hose mandrel for the pump SEAFLO/Shurflo
    Skladem (116 pcs)
    2 € incl. VAT
    2 €

    Hose barb for diaphragm pump SEAFLO, SHURFLO, Lilie, female thread1/2"

    Code: 51F01
    expanzni nadoba do karavanu Create Flow
    Expansion vessel 1,0 l
    Skladem (3 pcs)
    61 € incl. VAT
    50 €

    Damper for damping the water shock in the pipe.A damper or storage tank allows the pump to achieve a smoother flow and dampen shocks in the pipe when the tap is closed and...

    Code: SFAT-100-125-01
    obrázek 1
    Expansion vessel 0,75l
    Skladem (20 pcs)
    51 € incl. VAT
    42 €

    Damper for damping the water shock in the pipe.A damper or storage tank allows the pump to achieve a smoother flow and dampen shocks in the pipe when the tap is closed and...

    Code: SFAT-075-125-01
    Zpetna klapka filtr pro cerpadla na 12V Create Flow
    Sucking basket - check valve
    Skladem (2 pcs)
    19 € incl. VAT
    15 €

    Brass check valve with basket. The return flap is fitted with a spring. Connection internal thread 3/4"-1/2" - hose shank 15 mm (1/2") or 10 mm (3/8") according to pump...

    Code: 9682
    tlakovy spinač cerpadlo na12V Create Flow
    Pressure switch for the pump SEAFLO 51,52,54, CFFL55701T12
    Skladem (47 pcs)
    18 € incl. VAT
    15 €

    Pressure switch for diaphragm pump SEAFLO 51,52,54, CFFL55701T12 including micro switch.

    Code: PS-CF55
    Hadice SEAFLO Create Flow
    PVC hose 1/2" 12,7/17 Clear
    Skladem (25 m)
    1 € incl. VAT
    1 €

    Clear hose, for diaphragm pumps material PVC, size 1/2", available in 1 m

    Code: 3351PVC12
    51F008
    Hadicový trn pro čerpadlo SEAFLO/Shurflo
    Skladem (28 pcs)
    7 € incl. VAT
    6 €

    Hose barb for diaphragm pump SEAFLO, SHURFLO, Lilie, female thread1/2"

    Code: 51F08
    SEAFLO 51 Create Flow
    New
    Diaphragm pump Create Flow CF51, max. power 18,9 l/min, max. 4,2 bar, self-priming -1.8 m. Power supply 12 V DC Nejprodávanější čerpadlo
    Skladem (10 pcs)
    190 € incl. VAT
    157 €

    Powerful 12 V pump for pumping water, aqueous solutions. Max. output 18.9 l/min, max. 4.2 bar, self-priming capacity -1.8 m. The pump is suitable for waterworks, water...

    Code: CFFL55701T12
    cerpalo 12V SEAFLO Create Flow
    New
    SEAFLO 21 Performance 4.3 l/min, max. 2,4 bar, self-priming -1 m. 12 V power supply DC Nejprodávanější čerpadlo
    Skladem (6 pcs)
    73 € incl. VAT
    60 €

    Designed for pumping water, water solutions, fertilizers. Max. output 4.3 l/min, max. 2.4 bar, self-priming capacity -1 m. Power supply 12 V DC from car battery, solar panel,...

    Code: SFDP1-012-035-21
    cerpadlo pro karavany Create Flow
    Membránové čerpadlo SEAFLO33 Max.výkon 11,6 l/min, max. 3,1 bar, samonasávací -1.8 m. Napájení 12 V DC
    Přesný dodací termín na poptání
    0 € incl. VAT
    0 €
    Detail

    The most widely supplied diaphragm pump for pumping water in caravans, boats, motorhomes. Max. output 11,6 l/min, max. 3,1 bar. Easy regulation of output pressure. Self-priming...

    Code: SFDP1-030-045-33
    membranove cerapdlo na 12V Create Flow
    Diaphragm pump Create Flow CF22 Output 5 l/min, max. 7 bar, self-priming -1.8 m. Power supply 12 V DC SEAFLO 22 12V DC
    Skladem (24 pcs)
    94 € incl. VAT
    78 €

    Diaphragm pump for pumping water, aqueous solutions, fertilizers. Max. output 5 l/min, max. 7 bar, self-priming capacity -1.8 m. 12 V DC power supply from car battery, solar...

    Code: CFL-22-3203-V-12
    čerpadlo Create Flow bezkartáčový motor napájení 12V 24V DC Brushless motor Create Flow (2)
    Membránové čerpadlo Brushless motorem CFDP60 Výkon 5 l/min, max. 4,2 bar, samonasávací -1.8 m. Napájení 12 V DC SEAFLO 22 12V DC
    Skladem (2 pcs)
    189 € incl. VAT
    156 €

    Diaphragm pump for pumping water, aqueous solutions, fertilizers. Max. output 5 l/min, max. 7 bar, self-priming capacity -1.8 m. 12 V DC power supply from car battery, solar...

    Code: CFDP60ABLDC12
    SHURFLO Lilie SEAFLO 12V Create Flow
    Diaphragm pump Create Flow CF T33 Max. power 11,6 l/min, max. 3,1 bar, self-priming -1.8 m. Power supply 12 IN DC
    Skladem (8 pcs)
    176 € incl. VAT
    146 €

    The most widely supplied diaphragm pump for pumping water in caravans, boats, motorhomes. Max. output 11,6 l/min, max. 3,1 bar. Easy regulation of output pressure. Self-priming...

    Code: CFDPHC-T33-12
    Show all related products Previous product Next product

    Product detailed description

    The CF51 series pumps are designed for a wide range of applications including liquid pumping, spraying, circulation, filtration and dosing. The diaphragm pumps are self-priming (-1.8 m) and can be operated without pumping fluid (dry running) without damaging the pump. The integrated pressure switch function ensures safe operation of the pump. An integrated pressure sensor ensures that the pump is switched on when the pressure drops in the discharge pipe. When the tap on the discharge pipe is closed, the pump is stopped by a pressure rise.

    Maximum pump output is 18.9 l/min, maximum discharge pressure 4.2 bar. (The values are tabulated. Please refer to the attached power curve for exact performance).

    Čerpadlo na 12 V Create Flow

    Čerpadlo na zahradu 12 V DC Create Flow

    Čerpadlo na zahrádkářskou kolonii Create Flow

    čerpadlo na 12 V Create Flow

    čerpadlo na 12 V Create Flow

    Čerpadlo pro karavan Create Flow

    Čerpadlo pro zahradu na 12 V DC Create Flow

    Vysokotlaké čerpadlo na loď 12 V Create Flow

    Vysokotlaké čerpadlo na 24 V Create Flow

    Katalog SEAFLO Create Flow

    Additional parameters

    Category: Pumps 12 and 24 V DC
    Warranty: 2 roky vyjma dílů podléhající vysokému stupni opotřebení
    Weight: 3.02 kg
    Materiál tělesa čerpadla: Polypropylen
    Ventliy: EPDM
    Membrány: Santopren
    ? Max. výkon: 18,9 l/min
    Výtlak: 4,2 bar (42 m)
    Sání: -1,8 m
    Připojení sání/výtlak: 1/2" (14mm)/hadicový trn
    Maximální terplota: +60°C
    Funkce: integrovaný tlakový senzor
    Rozměr: 146 x 132 x 228 mm
    Elektromotor : 230V AC, 1,3 A
    Barva: Hlava čerpadla modrá, těleso motoru černé
    By-pass ventil: NE
    ? ATEX: Ne
    ? Ropné produkty: NE
    Krytí el. motoru: IP 42
