    Home / Produkty / Průmyslová automazice / Snímače polohy / Indukční snímače / Inductive sensor Standard class IP67 AI054

    Inductive sensor Standard class IP67 AI054

    Code: AI054
    Brand: Autosen
    AI054 et main 800 indukční snímač
    23 € / pcs 27 € incl. VAT 23 € / 1 pcs
    Skladem na externím skladu
    Delivery to:
    13/02/2025
    • Degree of protection IP67
    • Embedded
    • 5 years warranty
    • With switchable LED display

    The standard M12 inductive transducer with inductive measurement class AI054 can be used in all standard applications and is characterized by its short nickel-plated brass housing. The AI054 has a switching output with normally open function, an increased switching distance of 4 mm, a high degree of protection IP67 and an M12 connector. The cabinet is equipped with versatile visible LEDs for switching indication

    Two mounting nuts are included with AI054



    Detailed information

    Related products

    AA902 et main 800
    Mounting bracket M12 AA902
    Skladem na externím skladu
    12 € incl. VAT
    10 €

    For safe and optimal installation of M12 sensors.

    Code: AA902
    AA037 et main 800 kabel snímače
    Sensor cable 2 m Standard class IP67 AA037
    Skladem na externím skladu
    17 € incl. VAT
    14 €

    Sensor cable with direct connection connector Degree of protection IP 65 | IP67 AC/DC

    Code: AA037
    AA040 et main 800 kabel snímače Create Flow
    Sensor cable 2 m Standard IP class 67 AA040
    Skladem na externím skladu
    18 € incl. VAT
    15 €

    Sensor cable with angled connection Degree of protection IP 65 | IP67 AC/DC

    Code: AA040
    AA947 et main 800 konektor L
    Connector M12 AA947
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA947
    AA946 et main 800 konektor L
    Connector M12 AA946
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA946
    AA939 et main 800 Konektor pro kabel senzoru
    Connector M12 AA939
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA939
    AA921 et main 800 konektor
    Connector M12 AA921
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA921
    AN001 et main 800
    Single channel switching amplifier AN001
    Skladem na externím skladu
    215 € incl. VAT
    178 €

    The AN001 single channel switching amplifier is used to supply and evaluate sensor signals. It is equipped with a 24 V DC / 300 mA output, a clamp rail housing and is...

    Code: AN001
    AN002 et main 800
    Dual stream management switching amplifiers AN002
    Skladem na externím skladu
    317 € incl. VAT
    262 €

    The two-position control relay has an enclosure with a clamping rail and offers an input delay of 0 ... 10 s. Switching outputs: relay (1 switching contact); Transistor output...

    Code: AN002
    AR003 et main 800
    Monitor speed AR003
    Skladem na externím skladu
    260 € incl. VAT
    215 €

    Position sensors can be combined with the AR003 evaluation system to detect pulses, velocities or stops of non-metallic objects. Intuitive adjustment of pulse count, output...

    Code: AR003
    Show all related products Previous product Next product

    Product detailed description

    Technical data AI054

    General information

    mm
    2000 Hz

    Outputs / inputs

    normally open (NO)

    Electrical data

    Yes
    10 ... 30 V DC
    Yes
    Yes
    DC
    PNP
    200 mA
    1.8 V
    10 mA

    Mechanical data

    PBT
    with thread
    nickel-plated brass
    gold-plated M12 contacts with 3 pins


    52,3 mm

    accuracy

    St37 = 1
    V2A approx. 0.7
    Ms approx. 0.5
    AI approx. 0.4
    Cu approx. 0.3
    ... 20% of the actual switching distance Sr

    environmental conditions

    . -25°C
    70°C
    IP67

    Further information

    x LED
    visible all around
    yellow
    fixing nuts
    DIN EN 60947-5-2
    DIN EN 60947-5-2
    DIN EN 60947-5-2
    CE
    cULus

    Additional parameters

    Category: Indukční snímače
    Warranty: 5 let
    Weight: 0.1 kg
