    Inductive sensor Standard class IP67 AI006

    Code: AI006
    Brand: Autosen
    AI006 et main 800 Indukční símač pro standardní aplikace
    43 € / pcs 52 € incl. VAT 43 € / 1 pcs
    Skladem na externím skladu
    Delivery to:
    13/02/2025
    • Active surface adjustable in 5 positions.
    • DC, 10 ... 36 V, normally open, PNP
    • Degree of protection IP67

    The advantage of the AI006 inductive sensor in the cubic design is the increased switching distance to 20 mm and the variable in 5 positions per activatable active detection area. Inductive proximity switch is NO switching contact and switching distance is 20mm

    Further technical data and suitable accessories (sensor cable AA005, AA006, AA007, AA008, mounting bracket AA905) are listed in the detailed data sheet.

    Detailed information

    Related products

    AA947 et main 800 konektor L
    Connector M12 AA947
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA947
    AA946 et main 800 konektor L
    Connector M12 AA946
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA946
    AA939 et main 800 Konektor pro kabel senzoru
    Connector M12 AA939
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA939
    AA921 et main 800 konektor
    Connector M12 AA921
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    Gold plated contacts Halogen and silicone free AC/DC

    Code: AA921
    AA905 et main 800
    Assembly board AA905
    Skladem na externím skladu
    24 € incl. VAT
    20 €

    For safe and optimal sensor installation.

    Code: AA905
    AN001 et main 800
    Single channel switching amplifier AN001
    Skladem na externím skladu
    215 € incl. VAT
    178 €

    The AN001 single channel switching amplifier is used to supply and evaluate sensor signals. It is equipped with a 24 V DC / 300 mA output, a clamp rail housing and is...

    Code: AN001
    AN002 et main 800
    Dual stream management switching amplifiers AN002
    Skladem na externím skladu
    317 € incl. VAT
    262 €

    The two-position control relay has an enclosure with a clamping rail and offers an input delay of 0 ... 10 s. Switching outputs: relay (1 switching contact); Transistor output...

    Code: AN002
    AR003 et main 800
    Monitor speed AR003
    Skladem na externím skladu
    260 € incl. VAT
    215 €

    Position sensors can be combined with the AR003 evaluation system to detect pulses, velocities or stops of non-metallic objects. Intuitive adjustment of pulse count, output...

    Code: AR003
    Show all related products Previous product Next product

    Product detailed description

    Technical data AI006

    General information

    20 mm
    100 Hz

    Outputs / inputs

    normally open (NO)

    Electrical data

    Yes
    10 ... 36 V DC power class 2 cULus
    Yes
    Yes
    DC
    PNP
    200 mA
    2.5 V
    20 mA

    Mechanical data

    polyamide (PA)
    recessed
    Polyamide (PA)
    gold-plated M12 contacts with 3 pins


    mm

    accuracy

    St37 = 1
    V2A approx. 0.7
    Ms approx. 0.5
    Al approx. 0.4
    Cu approx. 0.3

    environmental conditions

    . -25°C
    70°C
    IP67

    Further information

    years
    indicator green 2 x LED
    No accessories
    EN 60947-5-2
    CE
    cULus


    : LED yellow
    2: LED green

    Additional parameters

    Category: Indukční snímače
    Warranty: 2 years
    Weight: 0.1 kg
