    Home / Produkty / Průmyslová automazice / Snímače polohy / Indukční snímače / Inductive sensor Standard class IP67 AI050

    Inductive sensor Standard class IP67 AI050

    Code: AI050
    Brand: Autosen
    AI050 et main 800 Indukční snímač
    33 € / pcs 40 € incl. VAT 33 € / 1 pcs
    Skladem na externím skladu
    Delivery to:
    13/01/2025
    • Degree of protection IP67
    • Embedded
    • With switchable LED display

    The AI050 is a standard class inductive encoder in M8 design with an increased switching distance of 2 mm and normally open function - for reliable use in all standard applications

    The housing is made of nickel-plated brass and the device has a high IP67 rating and a versatile LED switching display. AI050 is very well protected against electronic damage and interconnection. With M8 connector

    AI050 is supplied with two mounting nuts

    Detailed information

    Related products

    AA901 et main 800
    Mounting bracket M8 AA901
    Skladem na externím skladu
    13 € incl. VAT
    11 €

    For safe and optimal installation of M8 sensors.

    Code: AA901
    AA001 et main 800 kabel snímače
    Sensor cable 2 m PUR M8 3 pole IP 69 AA001
    Skladem na externím skladu
    22 € incl. VAT
    18 €

    AC/DC Protection IP 67 | IP 68 | IP 69K Vibration and shock resistant

    Code: AA001
    AA002 et main 800 kabel snímače
    Sensor cable 5 m PUR M8 3 pole IP 69 AA002
    Skladem na externím skladu
    24 € incl. VAT
    20 €

      Vibration and shock resistant Protection IP 67 | IP 68 | IP 69K AC/DC

    Code: AA002
    AA003 et main 800 kabel snímače
    Sensor cable 2 m PUR M8 3 pole IP 69 AA003
    Skladem na externím skladu
    25 € incl. VAT
    20 €

    DC PNP Protection IP 67 | IP 68 | IP 69K 2 LEDs for switching and controlling the display

    Code: AA003
    AN001 et main 800
    Single channel switching amplifier AN001
    Skladem na externím skladu
    215 € incl. VAT
    178 €

    The AN001 single channel switching amplifier is used to supply and evaluate sensor signals. It is equipped with a 24 V DC / 300 mA output, a clamp rail housing and is...

    Code: AN001
    AN002 et main 800
    Dual stream management switching amplifiers AN002
    Skladem na externím skladu
    317 € incl. VAT
    262 €

    The two-position control relay has an enclosure with a clamping rail and offers an input delay of 0 ... 10 s. Switching outputs: relay (1 switching contact); Transistor output...

    Code: AN002
    AR003 et main 800
    Monitor speed AR003
    Skladem na externím skladu
    260 € incl. VAT
    215 €

    Position sensors can be combined with the AR003 evaluation system to detect pulses, velocities or stops of non-metallic objects. Intuitive adjustment of pulse count, output...

    Code: AR003
    AA004 et main 800 Kabel snímače
    Sensor cable 5 m PUR M8 3 pole IP 69 AA004
    Skladem na externím skladu
    27 € incl. VAT
    22 €

    DC PNP Protection IP 67 | IP 68 | IP 69K 2 LEDs for switching and controlling the display

    Code: AA004
    Show all related products Previous product Next product

    Product detailed description

    Technical data AI050

    General information

    mm
    5000 Hz

    Outputs / inputs

    normally open (NO)

    Electrical data

    Yes
    10 ... 30 V DC
    Yes
    Yes
    DC
    PNP
    200 mA
    1.8 V
    10 mA

    Mechanical data

    PBT
    with thread
    recessed
    nickel-plated brass

    gold-plated contacts
    3-pin
    50 mm

    accuracy

    St37 = 1
    Ms approximately 0.5
    Al approx. 0.4
    Cu approx. 0.3
    V2A approx. 0.8
    ... 20% of the actual switching distance Sr

    environmental conditions

    . -25°C
    IP67

    Further information

    LED indication
    4 x LED all around visible yellow
    fixing nuts
    EN 60947-5-2
    DIN EN 60947-5-2
    DIN EN 60947-5-2
    CE
    cURus

    Additional parameters

    Category: Indukční snímače
    Warranty: 5 let
    Weight: 0.1 kg
